Disposable Pediatric Pads – Essential AED pad (1)

Disposable Pediatric Pads – Essential AED pad Compatible with NF1200 AED Defibrillator.

• MODEL: NF1200
• NF1200 AED Defibrillator Defibrillator: Operation mode: Automatic, Waveform: e-cube biphasic (Truncated exponential type), Energy:150-200J (escalating) Adult: nominal 150 Joules into a 50 ohm load. Infant/Child: nominal 50 Joules into a 50ohm load.
• Shock to Shock Cycle Time: Typically less than 20 seconds
• Protocol: Voice prompts and indicators guide user though protocolFollows preconfigured settings. Can be modified with software.
• Voice Instructions: Detailed voice messages guide responder through use of the defibrillator
• Controls: Shock Button, i-Button, On/off Button
• Indicators: 7 LEDs (different colors), i-Button
• Environmental/Physical Requirements: Temperature: 0° ~ 50°, Humidity: -0% ~ 95%, Vibration: Meets EN1789 random and swept sine, road ambulance specification in operating and standby states. EMI (Radiated/ Immunity): Meets EN55011 Group1 Level B Class B and EN61000-4-3
• Battery: Type: 12 Volt DC, 4.2Ah, lithium manganese dioxide, disposable long lifeprimary cell. Battery Life, 200 shock / 10 hours or 2 years. Capacity: Minimum 120 shocks or 4 hours of operating time.
• Automated and User-Activated Self-Tests: Daily Self-tests: Tests internal circuitry, waveform delivery system,battery capacity, and software. Battery Insertion Test: Upon battery insertion, extensive automatic self-tests and user–interactive tests check device readiness
• Physical: Size: 220mmW x 260mmL x 70mmH, Weight: 2,2Kg
• Data Recording and Transmission (OPTIONAL): Infrared: Wireless transmission of event data to personal computer using theIrDA protocol. Data Stored: First 40 minutes of ECG and the entire incident’s events and analysis decisions

• Compatible with NF1200 AED Defibrillator
• Operation mode: Automatic
• Waveform: e-cube biphasic (Truncated exponential type)
• Energy:150-200J (escalating)
• Shock to Shock Cycle Time: Typically less than 20 seconds
• Voice prompts and indicators guide user though protocol
• Detailed voice messages guide responder through use of the defibrillator
• Controls: Shock Button, i-Button, On/off Button
• Indicators: 7 LEDs (different colors), i-Button
• Battery Type: 12 Volt DC, 4.2Ah, lithium manganese dioxide, disposable long lifeprimary cell
